Deep Drawing Press Machine
>
|
| Place of Origin | CHINA |
| Brand Name | OEM |
| Certification | CE ISO |
High Performance Hydraulic Press Deep Drawing Press Machine For LPG Cylinder Manufacture
The deep drawing process involves placing a metal sheet on a die and then pressing it into the die cavity to create the desired shape. The depth of the cavity determines the depth of the formed part. The process requires a high level of precision and accuracy, as even a slight variation in the pressure or the position of the metal sheet can lead to defects in the finished product.
LPG deep drawing press machines come in different sizes and capacities, depending on the requirements of the manufacturing process. They can be operated manually or using automated controls, depending on the level of automation required for the process. The machines require regular maintenance and servicing to ensure their proper functioning and to minimize downtime.
General Properties of the Deep Drawing Press
The main characteristics of the hydraulic deep drawing press for LPG Cylinder Production:
|
Frame type: |
|
H Frame |
|
Number of Hydraulic Cylinders |
|
1 |
|
Ram Stroke |
mm |
1.200 |
|
Daylight |
mm |
1.400 |
|
Useful bottom table size (L to R) width |
mm |
1.200 |
|
Useful bottom table size (F to B) depth |
mm |
1.000 |
General Working Speeds of the Hydraulic Press:
|
Fast approach speed: |
mm/sec |
50 |
|
Maximum Pressing speed: |
mm/sec |
50 |
|
Return speed |
mm/sec |
500 |
|
Working pressure |
bar |
265 |
|
Drive motor power |
kW |
90 |
|
Power consumption (approx.) |
kW |
110 |
Deep Drawing Operation Cycle Time:
|
Deep Drawing Operation: |
8 seconds |
What Service Do We Provide?
FAQ
Q: What size of LPG cylinder your machine can produce?
A: 6kg, 12kg,15kgs and 50kgs LPG cylinder for cooking and other size according customers' requirement.
Q: Can you design machines according LPG cylinder technical drawing?
A: Sure, please send your technical drawing to us.
Q: What are the benefits to choose your machines?
A: Our machines are strong and reliable for long term industrial manufacturing
We need to know following information to quote you correct machines:
1. Technical Drawing of the cylinders you want to make?
2. What size of cylinder you want to produce?(such as 6kg, 12kg)
3. What diameter and thickness of the cylinder you want to make?
4. Are you new in this area or you already have some machines in the workshop?
5. Capacity you require, i.e. how many pieces and sizes you want to make per day?
