4mm LPG Cylinder Trimming And Beading Machine Hydraulic Pressure 200 Bar
  • 4mm LPG Cylinder Trimming And Beading Machine Hydraulic Pressure 200 Bar

4mm LPG Cylinder Trimming And Beading Machine Hydraulic Pressure 200 Bar

Place of Origin CHINA
Brand Name OEM
Certification CE ISO
Product Details
Product Name:
LPG Cylinder Trimming And Beading Machine
Max. Work Pc Diameter:
350 Mm
Max. Work Pc Height:
400 Mm
Min. Work Pc Height:
200 Mm
Max. Material Thickness:
4 Mm
Main Motor Power:
7.5 KW
High Light:

4mm LPG Cylinder Trimming And Beading Machine

,

4mm LPG Cylinder Trimming Machine

,

4mm LPG Cylinder Beading Machine

Product Description

LPG Cylinder Trimming Cleaning and Beading Machine Max. Work Pc Diameter 350 Mm



An LPG trimming and beading machine is a piece of equipment used in the manufacturing process of LPG cylinders. The machine is designed to trim and bead the top and bottom edges of the cylinder to ensure that they are smooth and safe to handle.

The trimming process involves removing any excess metal from the edges of the cylinder, while the beading process involves rolling the edges to create a rounded, smooth finish. This helps to prevent injury to workers and ensures that the cylinders can be safely transported and stored.


(Note: According to the customer request, properties will change)

Max. work pc diameter 350 mm
Max. work pc height 400 mm
Min. work pc height 200 mm
Max. material thickness 4mm
Spindle speed 140 rpm
Main motor power 7.5 kW
Hydraulic drive motor power 4 kW
Hydraulic pressure 200 bar





What Service Do We Provide?

Pre-sales Service: Customized design of the overall production line scheme according to customer site, environment, output, budget, and product requirements
On-sale Service: Tracking the manufacturing progress of the whole line of equipment, quality control, product proofing and trial production
After-Sales Service: Equipment installation, testing, training, project acceptance
Maintenance Service: Regular inspection and maintenance of the entire line, providing genuine accessories, 24-hour online service





FAQ
Q: What size of LPG cylinder your machine can produce?
A: 6kg, 12kg,15kgs and 50kgs LPG cylinder for cooking and other size according customers' requirement.

Q: Can you design machines according LPG cylinder technical drawing?
A: Sure, please send your technical drawing to us.

Q: What are the benefits to choose your machines?
A: Our machines are strong and reliable for long term industrial manufacturing

We need to know following information to quote you correct machines:
1. Technical Drawing of the cylinders you want to make?
2. What size of cylinder you want to produce?(such as 6kg, 12kg)
3. What diameter and thickness of the cylinder you want to make?
4. Are you new in this area or you already have some machines in the workshop?
5. Capacity you require, i.e. how many pieces and sizes you want to make per day?
