We can provide you: Diesel generators from 10kw to 3800kw, Marine diesel generators from 40kw to 2000kw, Gas generators from 20kW to 4000kw, Small petrol generators 1kW to 10kw.We can provide you: Diesel generators from 10kw to 3800kw, Marine diesel generators from 40kw to 2000kw, Gas generators from 20kW to 4000kw, Small petrol generators 1kW to 10kw.
Generator | Model | JD7500T |
Rated Output kVA(kW) | 5(5kW) | |
Max. Output kVA(kW) | 5.5(5.5kW) | |
Power Factor cos | 1 | |
100% Copper Coil | √ | |
AVR | √ | |
AC Load (Volts) | 230/240 | |
Phase, Frequency | Single,50Hz | |
Rated.Amperage | 21.7 | |
Engine | Starting Method | Electric |
Engine Type | 1-cylinder,vertical ,4-stroke,air-cooled diesel engine,direct injection | |
Engine Model | JD188FAE | |
Displacement cc | 456 | |
Horse Power hp | 10 | |
Fuel Tank Capacity (L) | 15 | |
100% Load (Hrs) | 6 | |
Engine Oil Capacity | 1.65L | |
dBA at 23ft (7m) | 73 | |
Control Panel |
Panel Type | General |
AC VoltMeter | √ | |
Low Oil Alert Lamp | √ | |
Socket | Optional | |
Others | Structure type | Silent |
Battery | 12V 30AH | |
Socket | Negotiate | |
Wheel Kits | 4x4" wheels | |
Packing | Net Weight (kgs) | 150 |
Gross Weight (kgs) | 160 | |
Packing(L*W*H,mm) | 940*560*760 | |
Q'ty(20GP/40HQ) | Negotiate | |
Warranty | Year / Hours | 1 / 250 |
The actual production be desiged according to different country standard
Our products had been approved by CE, EPA, CARB,Canada CSA standard, EII emission standard,GS standard, and ISO9001:2000. Products served to EU,North America, Middle East, Africa, Australia,Russia and so on, over 70 countries and regions,especially providing service for global well-known brand.
