1400 mm LPG Cylinder Bottom Ring Production Line Ring Press Coil
An LPG cylinder bottom ring production line is an industrial process used to manufacture the bottom rings of LPG cylinders. The bottom ring is an essential component of the LPG cylinder, providing support and stability to the cylinder when it is in use.
The production line typically consists of several machines and processes that work together to manufacture the bottom rings. These machines may include a steel strip slitting machine, a roll forming machine, a welding machine, and a trimming machine.
The production process typically begins with the steel strip slitting machine, which cuts the steel strip into the appropriate width and length for the bottom ring. The strip is then fed into the roll forming machine, which shapes the strip into a circular form.
Specification:
| Product Name: | LPG Cylinder Bottom Ring Production Line Ring Press |
| Max. Coil Weight: | 6.000 Kg |
| Max. Stock Weight: | 1200 Mm |
| Max Coil Outer Diameter: | 1400 Mm |
| Coil Inner Diameter Range: | 460-540 Mm (standard) |
What Service Do We Provide?
| Features | 1. 1 or 2 torches are usually built in.2. Multiple torches up to 4-5 also could be integrated into this machine based on qnty. of welding seam and productivity. 3. Adjustable for various thickness 4. Precision longitudinal track for smooth travel 5. Change size automatically or manually |
| Applications | Our precision Circumferential Lathe Welder are most commonly used in tank production. * High pressure type solar water heater tank * Low-pressure type solar water heater tank * Enamel tank for electrical water heater * LPG cylinder * LNG gas station * Cryoease * Storage tank |
| Range of working piece | Thickness of working piece: 0.3mm-10mm Dia. of working piece: 200mm-2500mm |
| Custom Designed |
For any welders we fabricate and install, we can incorporate the controls system necessary. We program and wire electrical
controls such as: * Programmable Logic Controllers (PLCs) * Standard Push Button Controls * Emergency Stop Buttons * Safety Sensors * Audiovisual Alarms * Data Acquisition We use predominantly Allen-Bradley PLCs with touch-screen or panel view displays but we will incorporate any brand or type of controls our customers specify |
FAQ
Q: What size of LPG cylinder your machine can produce?
A: 6kg, 12kg,15kgs and 50kgs LPG cylinder for cooking and other size according customers' requirement.
Q: Can you design machines according LPG cylinder technical drawing?
A: Sure, please send your technical drawing to us.
Q: What are the benefits to choose your machines?
A: Our machines are strong and reliable for long term industrial manufacturing
We need to know following information to quote you correct machines:
1. Technical Drawing of the cylinders you want to make?
2. What size of cylinder you want to produce?(such as 6kg, 12kg)
3. What diameter and thickness of the cylinder you want to make?
4. Are you new in this area or you already have some machines in the workshop?
5. Capacity you require, i.e. how many pieces and sizes you want to make per day?
