Galvanized Steel Bottom Ring LPG Cylinder Manufacturing Machinery 6000kg
  • Galvanized Steel Bottom Ring LPG Cylinder Manufacturing Machinery 6000kg

Galvanized Steel Bottom Ring LPG Cylinder Manufacturing Machinery 6000kg

Place of Origin CHINA
Brand Name OEM
Certification CE ISO
Product Details
Product Name:
LPG Cylinder Bottom Ring Production Line Ring Press
Max. Coil Weight:
6000kg
Max. Stock Weight:
1200 Mm
Max Coil Outer Diameter:
1400 Mm
Coil Inner Diameter Range:
460-540 Mm (standard)
High Light:

Galvanized Steel LPG Cylinder Manufacturing

,

Galvanized Steel LPG cylinder bottom ring production

,

Galvanized Steel Bottom Ring Manufacturing Machinery

Product Description

Gavalized Steel LPG Cylinder Bottom Ring Production Line Ring Press Coil Stainless Steel



A production line for LPG cylinder bottom ring production typically includes a ring press machine that is used to form the bottom ring of the cylinder. The ring press machine applies pressure to a flat sheet of metal, causing it to take the shape of a ring. This ring will eventually be welded to the cylinder body to form the bottom of the LPG cylinder.

The ring press machine is typically equipped with a set of dies that are used to shape the metal sheet into the desired form. The dies are often made from hardened steel and can be customized to produce rings of different sizes and shapes.





Specification:

Product Name: LPG Cylinder Bottom Ring Production Line Ring Press
Max. Coil Weight: 6.000 Kg
Max. Stock Weight: 1200 Mm
Max Coil Outer Diameter: 1400 Mm
Coil Inner Diameter Range: 460-540 Mm (standard)





What Service Do We Provide?

Pre-sales Service: Customized design of the overall production line scheme according to customer site, environment, output, budget, and product requirements
On-sale Service: Tracking the manufacturing progress of the whole line of equipment, quality control, product proofing and trial production
After-Sales Service: Equipment installation, testing, training, project acceptance
Maintenance Service: Regular inspection and maintenance of the entire line, providing genuine accessories, 24-hour online service





FAQ
Q: What size of LPG cylinder your machine can produce?
A: 6kg, 12kg,15kgs and 50kgs LPG cylinder for cooking and other size according customers' requirement.

Q: Can you design machines according LPG cylinder technical drawing?
A: Sure, please send your technical drawing to us.

Q: What are the benefits to choose your machines?
A: Our machines are strong and reliable for long term industrial manufacturing

We need to know following information to quote you correct machines:
1. Technical Drawing of the cylinders you want to make?
2. What size of cylinder you want to produce?(such as 6kg, 12kg)
3. What diameter and thickness of the cylinder you want to make?
4. Are you new in this area or you already have some machines in the workshop?
5. Capacity you require, i.e. how many pieces and sizes you want to make per day?
